Water Bath Cum Water Bath Shaker

Description

(Touch Screen Version) Safety Features Water bath and shaker in a single system. Selection of mode in the touch screen Absolutely noiseless operation. Programmable system Removable tray Flexible Polyproplene Rubber Clamps reinforced with inner metallic cup for sturdy & rugged use for intact grip to perfectly hold the flask Technical Specification: Model 1800.DNEU.03 Operation Water bath or water bath shaker Material of construction MS with powder coated finish Type of motion Reciprocal motion SPM range 50 to 150 Strokes per minute Movement Linear link guided drive mechanism Movement sensor IR scan sensor Motor Stepper servo motor (Brushless) Drive Servo drive Process controller 4.3” TFT touch screen controller Display Feather touch membrane key pad with touch controller (Power, Heater) Temperature controller PID controller Temperature range 5 Degree above ambient to 100 Degree Temperature accuracy +/- 0.5Degree Temperature sensor Pt 100 No of program 1 program, 5 steps for both shaker and water bath Programmable For Strokes Per M inute, Temperature and Time Heater Immersion Heater Heater power 1500 W Water tank Stainless steel Tank capacity 15 lit Tray Stainless steel, Removable Tray capacity 250ml clamp-9 nos Hood or cover Stainless steel Internal Recirculation pump for Temperature stability Magnetic pump External recirculation pump (optional) magnetic pump Electrical requirement 230V/50Hz/ 6A Unit dimension 25 x 25 x15inches
