Description
HEATING MANTLE COMBINED UNIT WITH STIRRER 3 POSITION & 6 POSITION PU coated mild steel body Glass fibre mantle provides uniform heating of flask Uniform temperature distribution across the mantle Hot top indicator for user safety For Round Bottomed Flasks as per DIN 12347 Also Available with metallic stand 1101.DNEU Technical Specification: Heating Mantle Body : Mild steel Heating Mantle Material : Glass Fiber Yarn Mantle Capacity : Upto 500 ml Temperature Range : Approx. 400°C Heating Control : Energy regulator Dimensions : 495 x 246 x 200mm Permissible Ambient temperature : 5 – 40°C Weight of body : 10.2 Kg Permissible relative humidity : 80% Voltage : 230/115V Frequency : 50/60Hz DIN EN 60529 : IP 10 Also Known as : 2600.EU.01, 2600.EU.02, 2600.EU.03 , 2600.EU.04, 2600.EU.05, 2600.EU.06, 2000.DNEU.01,2000.DNEU.02,2000.DNEU.03,2000.DNEU.04,2000.DNEU.05,2000.DNEU.06
